File Mentah Lenovo TAB2 A7-30H Backup Cm2 Dongle.Firmware ini kami backup dari hp yang normal jaya guna untuk perbaikan masalah seperti Mati Total-Bootloop Nakal-Hang Logo dan macam kerusakan masalah OS lainya.guna mempermudah dalam eksekusi.kami juga sudah mencantumkan list preloader guna menghindari Brick dikarenakan preloader tidak mendukung.
List Model
Device Brand : Lenovo
Device Model : A7-30HC
Device CPU : MT6582
Device IntName : LenovoTAB2A7-30HC
Device Version : 4.4.2
Device Compile : 12/29/2014 7:42:37 AM
Device Project : A7-30HC_S0017_141229_ROW_MY
Device ExtInfo : Lenovo TAB 2 A7-30HC
Support Preloader
FlashID [0] CID : 150100513758534142 , Name : Q7XSAB , Vendor : 15 , [SAMSUNG]
FlashID [1] CID : 150100513858534142 , Name : Q8XSAB , Vendor : 15 , [SAMSUNG]
FlashID [2] CID : 90014A484147326505 , Name : HAG2e , Vendor : 90 , [HYNIX]
FlashID [3] CID : 90014A483847316505 , Name : H8G1e , Vendor : 90 , [HYNIX
Log Backup CM2 Dongle
Wait for phone...
Phone found! [ 47 ]
Sync...
Inital Boot Ok!
BB_CPU_PID : 6582
BB_CPU_NME : [MediaTek] MT6582_S00
BB_CPU_EXT : 0xCB00 , 0x8A00 , 0x0000
Processing BROM stage
Settings for BROM configured!
SecCfgVal : 0x00000000
BromVer : 0x00FF
BLVersion : 0x0001
PreLoader : Active [ Boot with PL ]
BootLdrSS : NORMAL with PRELOADER
Processing DA stage
DA Select done, will use MTK_AllInOne_DA_v5.1624.16.07
Sending and initialize DA ...
Running DA ver.4.2 on BBID : 0x87
NAND Flash : NOT INSTALLED
eMMC Flash : 90014A483847316505072A79E02B22D5
Initialize Memory ...
DRAM already initialized by Preloader
DAgent sent , init HW now
eMMC FlashIC initialized
[eMMC] : FLASH_VEN : 0x90 , OEM : 014A
[eMMC] : FLASH_INF : [HYNIX] , e1G8
[eMMC] : FLASH_CID : 90014A483847316505072A79E02B22D5
[eMMC] : FLASH_BRT : 0x00400000 , 0x00400000 , 0x00400000
[eMMC] : FLASH_LEN : 0x00000001D2000000
[eMMC] : FLASH_UCP : 7456 MiB [eMMC 8 GiB]
DEV RID : 0x07740D4B58C1FC9556E77C039EC09531
INT RAM : 0x00020000
EXT RAM : 0x40000000 [1 GiB]
BOOT TYPE : EMMC_FLASH_BOOT
SOC VERIFY : C1
Boot Ok!
[AP] : Initial info read Ok!
Brand : Lenovo
ProdName : LenovoTAB2A7-30HC
ProdModel : Lenovo TAB 2 A7-30HC
Device : A7-30HC
AndroidVer: 4.4.2
MTKxCPU : MT6582
MTKxPRJ : A7-30HC_S0017_141229_ROW_MY
MODEM :
BaseBand : MT6582_S00_MOLY_WR8_W1315_MD_WG_MP_V34_P2_1_wg_n
Done!
Elapsed: 00:00:04
Reconnect Power/Cable!
Operation : Read Flash [ v1.58 ]
1. Power Off Phone , Remove battery , Insert back
2. Insert USB cable. In some cases require hold BootKey
Wait for phone...
Device boot not done
Check Drivers
Try again
Boot Error!
Operation Failed
Elapsed: 00:00:29
Reconnect Power/Cable!
Operation : Read Flash [ v1.58 ]
1. Power Off Phone , Remove battery , Insert back
2. Insert USB cable. In some cases require hold BootKey
Wait for phone...
Phone found! [ 47 ]
Sync...
Inital Boot Ok!
BB_CPU_PID : 6582
BB_CPU_NME : [MediaTek] MT6582_S00
BB_CPU_EXT : 0xCB00 , 0x8A00 , 0x0000
Processing BROM stage
Settings for BROM configured!
SecCfgVal : 0x00000000
BromVer : 0x00FF
BLVersion : 0x0001
PreLoader : Active [ Boot with PL ]
BootLdrSS : NORMAL with PRELOADER
Processing DA stage
DA Select done, will use MTK_AllInOne_DA_v5.1624.16.07
Sending and initialize DA ...
Running DA ver.4.2 on BBID : 0x87
NAND Flash : NOT INSTALLED
eMMC Flash : 90014A483847316505072A79E02B22D5
Initialize Memory ...
DRAM already initialized by Preloader
DAgent sent , init HW now
eMMC FlashIC initialized
[eMMC] : FLASH_VEN : 0x90 , OEM : 014A
[eMMC] : FLASH_INF : [HYNIX] , e1G8
[eMMC] : FLASH_CID : 90014A483847316505072A79E02B22D5
[eMMC] : FLASH_BRT : 0x00400000 , 0x00400000 , 0x00400000
[eMMC] : FLASH_LEN : 0x00000001D2000000
[eMMC] : FLASH_UCP : 7456 MiB [eMMC 8 GiB]
DEV RID : 0x07740D4B58C1FC9556E77C039EC09531
INT RAM : 0x00020000
EXT RAM : 0x40000000 [1 GiB]
BOOT TYPE : EMMC_FLASH_BOOT
SOC VERIFY : C1
Boot Ok!
Reading Flash Content now ...
Brand : Lenovo
ProdName : LenovoTAB2A7-30HC
ProdModel : Lenovo TAB 2 A7-30HC
Device : A7-30HC
AndroidVer: 4.4.2
MTKxCPU : MT6582
MTKxPRJ : A7-30HC_S0017_141229_ROW_MY
[Read Ok] : preloader_huaqin82_tb_b2d_kk.bin
[Read Ok] : MBR
[Read Ok] : EBR1
[Read Ok] : lk.bin
[Read Ok] : boot.img
[Read Ok] : recovery.img
[Read Ok] : secro.img
[Read Ok] : logo.bin
[Read Ok] : system.img
[Read Ok] : cache.img
[Read Ok] : userdata.img
[ScatCFG] : MT6582 / V1.1.1 / huaqin82_tb_b2d_kk / EMMC
Android Info saved
MAUI Meta DB saved
HWConfig Info saved
FW Size : 1357 MiB
Scatter saved to : C:\Users\Ketua Teknisi HP\Desktop\MT6582__Lenovo__Lenovo_TAB_2_A7-30HC__A7-30HC__4.4.2__A7-30HC_S0017_141229_ROW_MY\
Kebutuhan FLahsing
Driver pack All ini One
Spflash Tool
MT6582__Lenovo__Lenovo_TAB_2_A7-30HC__A7-30HC__4.4.2__A7-30HC_S0017_141229_ROW_MY
Tutorial FLasing
Bagi yang belum paham tentang bagaimana cara flashing bisa lanjut di sini Cara FLash hp Android Semua Model.Selamat mencoba dan semoga sukses.
 |
